IK-12 Max-3 Koike Track Torch

[OE005038]

Capacity: 4-39 IPM

KOIKE

IK-12 MAX-3

115 VOLTS

Traveling Speed	80-800 mm/min. (3-31in./min.) 50Hz 100-1000 mm/min. (4-39in./min.) 60Hz
Speed Control	Double cone stepless system
Motor	Condenser type induction output 9/10W (50Hz/60Hz)
Speed Meter	Dial indication (w/conversion scale)
Weight	11.5kg (25lbs.) S-100 Model
Max. Loading Weight	50kg (100lbs.)
Overall Measurement	430(L) x 170(W) x 215(H) mm (17 x 7 x 8- 1/2in.)

Product Images:

Click to enlarge	Click to enlarge	Click to enlarge	Click to enlarge

Related Files:

CLICK HERE FOR SPEC'S
