Mitrowski Welding Equipment, LTD.

TC-3 High Capacity Travel Carriage Subarc Welding Equipment

[SW005004]

Capacity:

MANUFACTURE LINCOLN ELECTRIC

MODEL TC-3

CODE NUMBER 9020 TC-3 Self-Propelled High Capacity Travel Carriage

Product Number: K325HCS

Advantage Lincoln

Carries head and controls in either direction on a beam of suitable length. It operates either automatically with the weld controls or manually. The speed range, set with a continuous speed control without gear changes, is 5-75 ipm (.1-1.9 m/min). Requires 115V AC, 60 or 50 hertz power available from Lincoln power sources. For tandem arc (2 or 3 heads) and Twinarc®-tandem arc (up to 4 wires) installations.

Physical specifications

Weight:127 lbs. (57.61 kgs. )
Dimensions (in) H x W x D : 26.5 x 19.25 x 14.75
Dimensions (mm) H x W x D : 673.1 x 488.95 x 374.65
